| Cap size | 15*15mm |
|---|---|
| Cap Color | Transparent (Also available in black cap.) |
| Button height | 13mm |
| LED Color | RGB color (Available in white, blue, green, yellow, orange and Bi-color and WS2812 RGB color.) |
| Rating | 12 VDC, 50mA |
| Contact Resistance | 100mΩ MAX |
| Insulation Resistance | 500 V DC. 100MΩ MIN |
| Operating Force | 250 ± 80gf |
| Total Travel | 0.2±0.1mm |
| Operating Temperature | -20℃~70℃ |
| Life Cycle | 500,000 Cycles |
