Cap size | 7.5*7.5mm |
---|---|
Shell Size | 10*10mm |
Cap Color | Black |
Button height | 8.5mm |
LED Color | RGB color (Available in white, blue, green, yellow, orange and Bi-color and WS2812 RGB color.) |
Rating | 12 VDC, 50mA |
Contact Resistance | 100mΩ MAX |
Insulation Resistance | 500 V DC. 100MΩ MIN |
Operating Force | 250 ± 80gf |
Total Travel | 0.2±0.1mm |
Operating Temperature | -20℃~70℃ |
Life Cycle | 500,000 Cycles |
