| Cap size | Ø10mm |
|---|---|
| Shell Size | Ø12mm |
| Cap Color | Red & Green Bi-color (Available in white, blue, green, yellow, orange.) |
| Button height | 13.5mm |
| Rating | 0.1A 30VDC MAX, 0.1mA 5VDC MIN |
| Contact Resistance | 50 mΩ MAX |
| Insulation Resistance | 250V DC,100 MΩ MIN |
| Operating Temperature | -20℃~70℃ |
| Operating Force | 250Z±100 gf. |
| Life Cycle | 50,000 Cycle |
