| Display Format | 64×32 Dots |
|---|---|
| Display Mode | FSTN, Positive |
| Polarizer Mode | Transflective |
| Driving Method | 1/32Duty, 1/5 Bias, Vop 5.7V |
| Viewing Direction | 6 O’clock |
| Backlight | RGB LED |
| Interface | Serial Interface |
| Module Dimension | 19(L) ×18(W) ×14.5(H) |
| Viewing Area | 14.9(L) ×12.3(W) |
| Active Area | 13.4(L)×9.74(W) |
| Life Cycle | 2,000,000 Cycles |
